System And Components
309-0104 LINES GP-AUXILIARY FRESH WATERS/N JHL1-UP
Group No: 309-0104
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N0931 | 1 GASKET | 1 | |
| 4N1156 | 2 GASKET-REGULATOR COVER | 1 | |
| 3718119 | 3 HOSE (8-CM) | ||
| 7C0145 | 4 CORE AS-OIL COOLER (ENGINE)(ENGINE) | 1 | |
| 9S8752 | 5 NUT-FULL (3/8-16-THD) | 2 | |
| 8T4983 | 6 CLAMP-HOSE | 2 | |
| 1013120 | 7 SPACER (10.5X25X20-MM THK) | 2 | |
| 1217745 | 8 SLEEVE-RETAINER | 2 | |
| 1243393 | 9 COVER-WATER PUMP | 1 | |
| 1243401 | 10 HOUSING | 1 | |
| 1243402 | 11 HOUSING | 1 | |
| 1249052 | 12 GASKET (WATER TEMPERATURE REGULATOR) | 1 | |
| 1250434 | 13 SEAL-INTEGRAL | 1 | |
| 1264935 | 14 SEAL-INTEGRAL | 1 | |
| 1570670 | 15 CAP-DUST | 1 | |
| 2179060 | 16 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1549023 | VALVE-SAMPLING | 1 | |
| 2292282 | 17 BONNET-OIL COOLER | 1 | |
| 2485513 | 18 REGULATOR-WATER TEMPERATURE (92-DEG C) | 1 | |
| 2624167 | 19 BONNET-OUTLET | 1 | |
| 2626127 | 20 ELBOW AS | 1 | |
| 3084321 | 21 BRACKET | 1 | |
| 3087071 | 22 CLIP-2 PIECE | 1 | |
| 3087072 | 23 CLIP-2 PIECE | 1 | |
| 3090099 | 24 TUBE AS | 1 | |
| 3112827 | 25 TUBE AS-INLET (WATER) | 1 | |
| 1488409 | 26 PLUG AS | 3 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3813801 | 27 HOSE | 1 | |
| 3503565 | 28 TUBE AS | 1 | |
| 0S1571 | 29 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 31 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 32 BOLT (3/8-16X1-IN) | 3 | |
| 0T0055 | 33 BOLT (3/8-16X4.25-IN) | 1 | |
| 0T0065 | 34 BOLT (3/8-16X3.5-IN) | 2 | |
| 1090077 | 35 SEAL-O-RING | 2 | |
| 1440367 | 36 CLAMP-HOSE | 1 | |
| 1620177 | 37 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1A2029 | 38 BOLT (3/8-16X1.125-IN) | 9 | |
| 1F7958 | 39 NUT-FULL (1/2-13-THD) | 2 | |
| 2M1395 | 40 GASKET | 1 | |
| 1837263 | 41 PLUG AS | 2 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1488395 | 42 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3S9643 | 44 SEAL-LIP TYPE (WATER TEMPERATURE REGULATOR) | 1 | |
| 4M5281 | 45 BOLT (1/4-20X0.75-IN) | 4 | |
| 5M2894 | 46 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 5M6213 | 47 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P8245 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 3196208 | 49 ADAPTER AS | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2N0475 | 50 SEAL-O-RING | 2 | |
| 7X7731 | 51 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T4205 | 52 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4984 | 53 CLAMP-HOSE | 1 | |
| 8T7061 | 54 STUD (1/2-13X5.5-IN) | 2 | |
| 2747396 | 55 SENSOR GP-TEMPERATURE (ENGINE COOLANT) | 1 | |
| 9X6458 | 56 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
