296-2982 AIR CLEANER GP -CRANKCASE BREATHERS/N JHL1-UP

Group No: 296-2982
Part NumberPart NameQty
8D72091 BOSS4
8T49882 CLAMP-HOSE2
9M01643 CLAMP-HOSE1
14259914 SPACER (16.5X40X30-MM THK)4
20586735 HOSE1
24338436 HOSE-DISPOSAL1
24626237 AIR CLEANER GP1
29075178 BRACKET AS1
8T59128A NUT-WELD (3/8-16-THD)6
29629869 BRACKET AS1
305333210 BRACKET AS1
1F0750NUT-WELD (3/8-16-THD)6
4K9097NUT-WELD (5/16-18-THD)2
321657211 BRACE1
8T904312 BOLT (5/16-18X0.875-IN)2
1F785413 SPACER (11.01X19.05X49.21-MM THK)1
2A463914 BOLT (3/8-16X1.625-IN)4
9X888315 BOLT (5/8-11X2.75-IN)4
4D370416 WASHER-HARD (17X30X5-MM THK)4
4L645417 BOLT (3/8-16X1-IN)7
5M289418 WASHER-HARD (10.2X18.5X2.5-MM THK)4
5P107519 WASHER-HARD (10.2X22.5X3-MM THK)14
5P236920 CLIP (LOOP)2
5P411621 WASHER-HARD (8.8X20.5X2-MM THK)2
6V818922 NUT (5/16-18-THD)1
6V880123 NUT (3/8-16-THD)7
7X029024 BOLT (3/8-16X3.5-IN)1
7C692125 SPACER (11X20X22.8-MM THK)1
8T422426 WASHER-HARD (8.8X16X2-MM THK)2
8T489627 WASHER-HARD (10.2X18.5X2.5-MM THK)1
8T891128 BOLT (5/16-18X2-IN)1
