System And Components
462-7627 HOOD GP-TRUCKS/N LAJ1-648
Group No: 462-7627
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4703095 | 1 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 3T7857 | 2 PLUG-BUTTON | 12 | |
| 2074258 | 3 NUT (M20X1.5-THD) | 6 | |
| 3069504 | 4 HINGE AS | 2 | |
| 3206679 | 5 PROP AS | 2 | |
| 6V3538 | DOWEL | 1 | |
| 3464228 | 6 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 3464335 | 7 BRACKET AS | 4 | |
| 3464337 | 8 PLATE | 2 | |
| 3464398 | 9 HINGE AS | 1 | |
| 3464411 | 10 PLATE AS | 1 | |
| 3470991 | 11 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3471000 | 12 PLATE AS | 1 | |
| 3474474 | 13 STRUT AS | 4 | |
| 3474475 | 14 STRUT AS | 4 | |
| 3585498 | 15 PLATE | 1 | |
| 3726348 | 16 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3731420 | 17 PLATE AS | 1 | |
| 7X0752 | BOSS-WELD (M10X1.5X65-MM) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3723118 | PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3744839 | 18 PLATE AS | 2 | |
| 3744840 | 19 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4331576 | 20 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 4331577 | 21 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 4499142 | 22 PROP AS | 1 | |
| 6V3535 | DOWEL | 1 | |
| 4499144 | 23 PLATE AS | 1 | |
| 4509656 | 24 FILM-IDENTIFICATION (TERMINAL STRIP) | 1 | |
| 4525010 | 25 LATCH AS | 6 | |
| 4525011 | 26 PAWL | 3 | |
| 4533332 | 27 PANEL AS-HOOD | 1 | |
| 4533334 | 28 PANEL AS-HOOD | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 12 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8Y6368 | PAN-MOUNT | 2 | |
| 4533350 | 29 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 4549355 | 30 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 6 | |
| 4549356 | 31 PLATE AS | 1 | |
| 8X3178 | PLATE | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 8 | |
| 4549386 | 32 PLATE | 1 | |
| 4689971 | 33 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 17 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8Y6368 | PAN-MOUNT | 2 | |
| 4689981 | 34 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 1259738 | BLOCK | 1 | |
| 4694243 | 35 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 4694247 | 36 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 24 | |
| 8X3178 | PLATE | 3 | |
| 4703093 | 37 PLATE | 1 | |
| 4703099 | 38 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4703105 | 39 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4703109 | 40 PAWL | 3 | |
| 4746611 | 41 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1984766 | 42 WASHER-HARD (11X25X10-MM THK) | 16 | |
| 1984778 | 43 WASHER-HARD (13.5X30X12-MM THK) | 28 | |
| 2519567 | 44 NUT (M20X1.5-THD) | 12 | |
| 3445675 | 45 NUT (M10X1.5-THD) | 14 | |
| 3B4618 | 46 PIN-COTTER | 1 | |
| 3B4627 | 47 PIN-COTTER | 2 | |
| 4H4641 | 48 PIN | 1 | |
| 5P1076 | 49 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4116 | 50 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 7X7729 | 51 WASHER (11X25X3-MM THK) | 213 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4136 | 53 BOLT (M10X1.5X25-MM) | 132 | |
| 8T4139 | 54 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4183 | 55 BOLT (M12X1.75X40-MM) | 24 | |
| 8T4186 | 56 BOLT (M10X1.5X40-MM) | 16 | |
| 8T4189 | 57 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4195 | 58 BOLT (M10X1.5X30-MM) | 93 | |
| 8T4196 | 59 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4223 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4956 | 61 BOLT (M12X1.75X35-MM) | 4 | |
| 9D8353 | 62 PIN | 2 | |
| 5P5661 | 63 SEAL (0.1-M EACH) |
