System And Components
462-7627 HOOD GP-TRUCKS/N LAJ649-661
Group No: 462-7627
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T7857 | 1 PLUG-BUTTON | 12 | |
| 2074258 | 2 NUT (M20X1.5-THD) | 6 | |
| 3069504 | 3 HINGE AS | 2 | |
| 3206679 | 4 PROP AS | 2 | |
| 6V3538 | DOWEL | 1 | |
| 3464335 | 5 BRACKET AS | 4 | |
| 3464337 | 6 PLATE | 2 | |
| 3464398 | 7 HINGE AS | 1 | |
| 3464411 | 8 PLATE AS | 1 | |
| 3470984 | 9 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3470991 | 10 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3471000 | 11 PLATE AS | 1 | |
| 3474474 | 12 STRUT AS | 4 | |
| 0950843 | PIN-COTTER | 2 | |
| 0951313 | PIN-CLEVIS | 2 | |
| 3474475 | 13 STRUT AS | 4 | |
| 0950843 | PIN-COTTER | 2 | |
| 0951313 | PIN-CLEVIS | 2 | |
| 3585498 | 14 PLATE | 1 | |
| 3726348 | 15 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3731420 | 16 PLATE AS | 1 | |
| 7X0752 | BOSS-WELD (M10X1.5X65-MM) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3723118 | PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3744839 | 17 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3744840 | 18 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4331577 | 19 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 4499142 | 20 PROP AS | 1 | |
| 6V3535 | DOWEL | 1 | |
| 4499144 | 21 PLATE AS | 1 | |
| 4507656 | 22 PLATE | 1 | |
| 4525010 | 23 LATCH AS | 6 | |
| 4525011 | 24 PAWL | 3 | |
| 4533332 | 25 PANEL AS-HOOD | 1 | |
| 4533334 | 26 PANEL AS-HOOD | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 12 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8Y6368 | PAN-MOUNT | 2 | |
| 5363376 | 27 PLATE AS | 1 | |
| 4549386 | 28 PLATE | 1 | |
| 4689971 | 29 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 17 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8Y6368 | PAN-MOUNT | 2 | |
| 1502472 | PLATE | 1 | |
| 4689981 | 30 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 1259738 | BLOCK | 1 | |
| 4694243 | 31 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 4694247 | 32 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 24 | |
| 8X3178 | PLATE | 3 | |
| 4703093 | 33 PLATE | 1 | |
| 4703095 | 34 PLATE AS | 1 | |
| 4703099 | 35 SUPPORT AS | 1 | |
| 4703105 | 36 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4703109 | 37 PAWL | 3 | |
| 4746611 | 38 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4792171 | 39 BOLT AS | 19 | |
| 4874848 | 40 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 10 | |
| 4874851 | 41 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 6 | |
| 4874854 | 42 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4883971 | 43 BOLT AS | 26 | |
| 4883974 | 44 BOLT AS | 164 | |
| 5079646 | 45 PLATE AS | 1 | |
| 1984777 | 46 WASHER-HARD (11X25X10-MM THK) | 32 | |
| 1984778 | 47 WASHER-HARD (13.5X30X12-MM THK) | 28 | |
| 2519567 | 48 NUT (M20X1.5-THD) | 12 | |
| 3445675 | 49 NUT (M10X1.5-THD) | 14 | |
| 3B4618 | 50 PIN-COTTER | 1 | |
| 3B4627 | 51 PIN-COTTER | 2 | |
| 4H4641 | 52 PIN | 1 | |
| 5P1076 | 53 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4116 | 54 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 7X7729 | 55 WASHER (11X25X3-MM THK) | 14 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4139 | 57 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4183 | 58 BOLT (M12X1.75X40-MM) | 24 | |
| 8T4186 | 59 BOLT (M10X1.5X40-MM) | 16 | |
| 8T4189 | 60 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4196 | 61 BOLT (M10X1.5X35-MM) | 16 | |
| 8T4223 | 62 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4956 | 63 BOLT (M12X1.75X35-MM) | 4 | |
| 9D8353 | 64 PIN | 2 | |
| 5363375 | 65 PLATE | 1 | |
| 5P5661 | 66 SEAL (0.09-M EACH) | ||
| 5P5661 | 66A SEAL (0.05-M EACH) |
