System And Components
306-9418 LINES GP-ENGINE OILS/N SSP1-150
Group No: 306-9418
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1474348 | 1 SPACER (11X25X65-MM THK) | 2 | |
| 1923668 | 2 REDUCER AS | 1 | |
| 6V8940 | REDUCER-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2350273 | 3 TUBE AS | 1 | |
| 2416220 | 4 CONNECTOR | 1 | |
| 3198074 | 5 HOSE AS | 1 | |
| 3209725 | 6 HOSE AS | 1 | |
| 1368543 | 7 CONNECTOR | 1 | |
| 1488351 | 8 ELBOW AS | 1 | |
| 6V9849 | ELBOW | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2287102 | 9 SEAL-O-RING | 1 | |
| 3D2824 | 10 SEAL-O-RING | 1 | |
| 3D9428 | 11 CLIP | 2 | |
| 4J5477 | 12 SEAL-O-RING | 1 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6D3479 | 14 CLIP (LOOP) | 2 | |
| 6V1819 | 15 BOLT (M10X1.5X100-MM) | 2 | |
| 6V5039 | 16 CLIP (SLOT) | 1 | |
| 6V5040 | 17 CLIP (TAB) | 1 | |
| 6V5839 | 18 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6560 | 19 SEAL-O-RING | 1 | |
| 6V8149 | 20 NUT (M12X1.75-THD) | 1 | |
| 6V8397 | 21 SEAL-O-RING | 1 | |
| 6V8556 | 22 NUT (1-3/16-12-THD) | 1 | |
| 6V8675 | 23 BOLT (M12X1.75X35-MM) | 1 | |
| 6V9007 | 24 ELBOW | 1 | |
| 6V9746 | 25 SEAL-O-RING | 1 |
