570-9442 LINES GP-ENGINE OILS/N B7B2362-UP; WLR1-UP

Group No: 570-9442

Part Number	Part Name	Qty
2W1635	1 SPRING	1
9Y2099	2 FLANGE	3
2777634	3 COVER	1
2777652	4 COVER	1
2888948	5 ELBOW	1
3087224	6 TUBE	1
3142361	7 TUBE	1
3449285	8 RING	8
3449286	9 RING	2
3624241	10 VALVE-BYPASS	1
3716761	11 FLANGE	2
3716762	12 FLANGE	4
3911364	13 FLANGE	1
4164848	14 TUBE AS	1
4815897	15 FLANGE	1
4815898	16 FLANGE	4
4815899	17 ELBOW AS	1
1012862	DOWEL	2
4815907	18 TUBE	1
4815914	19 ELBOW	2
4866909	20 ADAPTER-OIL LINE	1
5086499	21 TUBE	1
1299454	22 FLANGE	2
1313718	23 SEAL-O-RING	7
1444613	24 ANGLE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
2094730	25 PLUG (M60X2-THD)(M60X2-THD)	1
2095798	26 SEAL-O-RING	1
2154639	27 SEAL-O-RING	2
2287100	28 SEAL-O-RING	2
2385082	29 SEAL-O-RING	1
2385084	30 SEAL-O-RING	1
2416157	31 PLUG (INTERNAL)	2
2416174	32 PLUG (M33X2-THD)(M33X2-THD)	2
2588734	33 SEAL-O-RING	1
2594600	34 SEAL-O-RING	2
2609153	35 PLUG (M10X1-THD)	2
2697885	36 SEAL-O-RING	12
5478611	37 ELBOW	1
5P8245	38 WASHER-HARD (13.5X25.5X3-MM THK)	6
6V1196	39 SEAL-O-RING	4
6V1820	40 BOLT (M10X1.5X30-MM)	4
6V3822	41 BOLT (M10X1.5X35-MM)	2
6V4248	42 BOLT (M10X1.5X25-MM)	4
6V4249	43 BOLT (M10X1.5X50-MM)	4
6V5839	44 WASHER (11X21X2.5-MM THK)	62
3118193	45 BOLT (M10X1.5X45-MM)	4
6V5843	46 BOLT (M10X1.5X45-MM)	12
8C2926	47 BOLT (M10X1.5X140-MM)	4
8C3076	48 SEAL-O-RING	3
8C3345	49 VALVE AS-FLUID SAMPLING	1
8C3445	50 CAP-DUST	1
8T0356	51 BOLT (M10X1.5X160-MM)	6
8T0643	52 BOLT (M10X1.5X80-MM)	13
8T0644	53 BOLT (M10X1.5X90-MM)	1
8T5030	54 BOLT (M10X1.5X120-MM)	4
8T5041	55 BOLT (M12X1.75X120-MM)	6
9S4181	56 PLUG (1-5/16-12-THD)	1
9S4183	57 PLUG (1-1/16-12-THD)	1
9X8271	58 BOLT-12 POINT HEAD (M10X1.5X45-MM)	4
1416518	59 SPACER (13.5X30X10-MM THK)	4
1608708	60 BRACKET AS	2
8T3490	NUT-WELD (M10X1.5-THD)	1
7X0909	61 BOLT (M12X1.75X140-MM)	2
