System And Components
324-9236 LINES GP-TURBOCHARGER WATERS/N B7B1-451
Group No: 324-9236
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3171134 | 1 BRACKET | 2 | |
| 3249241 | 2 HOSE AS | 4 | |
| 3249242 | 3 HOSE AS | 1 | |
| 3249243 | 4 HOSE AS | 1 | |
| 1327551 | 5 SPACER (11X19X6-MM THK) | 1 | |
| 2159090 | 6 ELBOW (90-DEG) | 2 | |
| 2168578 | 7 SEAL-O-RING | 16 | |
| 2502343 | 8 SEAL-O-RING | 18 | |
| 2M9780 | 9 SEAL-O-RING | 2 | |
| 2Y5829 | 10 NUT (M10X1.5-THD) | 2 | |
| 5G3676 | 11 GROMMET | 3 | |
| 6V1820 | 12 BOLT (M10X1.5X30-MM) | 3 | |
| 6V4248 | 13 BOLT (M10X1.5X25-MM) | 2 | |
| 6V5839 | 14 WASHER (11X21X2.5-MM THK) | 6 | |
| 6V8629 | 15 ELBOW | 2 | |
| 6V9832 | 16 CAP (ORFS) | 3 | |
| 6V9839 | 17 TEE-SWIVEL | 1 | |
| 6V9853 | 18 ELBOW | 2 | |
| 7S3916 | 19 CLIP (TAB) | 3 | |
| 7S3919 | 20 CLIP (SLOT) | 3 | |
| 8C4423 | 21 PLUG (M27X2-THD) | 4 | |
| 8T7494 | 22 CONNECTOR (STRAIGHT) | 10 |
