324-9236 LINES GP-TURBOCHARGER WATERS/N B7B2057-UP

Group No: 324-9236
Part NumberPart NameQty
31711341 BRACKET2
32492422 HOSE AS1
37110113 HOSE AS4
37151534 HOSE AS1
13275515 SPACER (11X19X6-MM THK)1
21590906 ELBOW (90-DEG)1
21685787 SEAL-O-RING16
25023438 SEAL-O-RING21
2Y58299 NUT (M10X1.5-THD)2
6V182010 BOLT (M10X1.5X30-MM)3
6V325111 SEAL-O-RING3
6V424812 BOLT (M10X1.5X25-MM)2
6V583913 WASHER (11X21X2.5-MM THK)6
6V862914 ELBOW2
8T538915 ELBOW1
6V983916 TEE-SWIVEL1
6V985317 ELBOW2
8C442318 PLUG (M27X2-THD)2
8T749419 CONNECTOR (STRAIGHT)13
8T188920 CLIP (SLOT)3
8T189021 CLIP (TAB)3
353795322 GROMMET3
6V9832CAP (ORFS)6
