Assembly
100%

296-7535 LINES GP-AIR -ATAACS/N SSP944-1018

Group No: 296-7535
Part NumberPart NameQty
19258211 CLAMP-HALF2
25141842 CLAMP8
28559253 HOSE2
30268494 HOSE2
42156175 TUBE AS1
42156156 TUBE AS1
37159437 CLAMP-V BAND4
31247848 HOSE2
31456769 TUBE AS1
314567710 TUBE AS1
314583711 HOSE4
315401612 CLAMP-V BAND4
317109113 BRACKET AS1
8R2186BOSS (M10X1.5X40-MM)1
317109414 PLATE2
317109515 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)4
8T3597NUT-WELD (M12X1.75-THD)2
317109716 BRACKET1
421560917 BRACKET AS1
421561218 BRACKET AS1
6V583919 WASHER (11X21X2.5-MM THK)18
173209020 SPACER (11X20X15-MM THK)1
190488521 SPACER (11X22X50-MM THK)1
7C692122 SPACER (11X20X22.8-MM THK)2
256444823 CLAMP-T BOLT16
3W967024 BOSS1
9M922425 SPACER (0.406X0.75X1.688-IN THK)2
5J580126 PIPE12
5M621427 PLUG (1/8-27 PTF)2
5P107628 WASHER-HARD (13.5X30X4-MM THK)2
7X254332 BOLT (M10X1.5X120-MM)12
7X772933 WASHER (11X25X3-MM THK)2
8R072134 SPACER (11X16X35-MM THK)3
8T412135 WASHER-HARD (11X21X2.5-MM THK)12
8T419536 BOLT (M10X1.5X30-MM)8
8T413937 BOLT (M12X1.75X30-MM)2
8T064338 BOLT (M10X1.5X80-MM)1
6V584339 BOLT (M10X1.5X45-MM)3
8T418340 BOLT (M12X1.75X40-MM)2
6V584241 BOLT (M10X1.5X40-MM)1
8T419642 BOLT (M10X1.5X35-MM)2
8T422343 WASHER-HARD (13.5X25.5X3-MM THK)2
6V798144 BOLT (M10X1.5X70-MM)2
6V523045 BOLT (M10X1.5X60-MM)3
421561446 PLATE2
