System And Components
326-8935 PIPE GP-EXHAUSTS/N SSP1-144
Group No: 326-8935
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4161 | 1 CLAMP | 2 | |
| 2429806 | 2 CLAMP AS | 2 | |
| 3028136 | 3 CLAMP-BAND | 7 | |
| 3060297 | 4 BELLOWS AS | 2 | |
| 3114099 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3114102 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3116207 | 7 TUBE AS | 1 | |
| 3195307 | 8 TUBE AS | 1 | |
| 3196019 | 9 TUBE AS | 1 | |
| 3273755 | 10 STRAP | 2 | |
| 3286841 | 11 TUBE AS | 1 | |
| 3286842 | 12 TUBE AS | 1 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6A5591 | 14 BOLT (M12X1.75X25-MM) | 4 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4172 | 18 BOLT (M10X1.5X80-MM) | 2 |
