System And Components
295-5218 DRIVE GP-FANS/N MWH1-422
Group No: 295-5218
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 2S6150 | 2 COVER-PULLEY | 1 | |
| 6N3641 | 3 PULLEY-TIGHTENER | 1 | |
| 8B2327 | 4 RING-RETAINING | 1 | |
| 8N5579 | 5 RETAINER | 1 | |
| 2431872 | 6 DRIVE GP-FAN | 1 | |
| 3158203 | 7 BRACKET | 1 | |
| 3158206 | 8 PULLEY-CRANKSHAFT (3-GROOVE) | 1 | |
| 3225108 | 9 ARM AS (BELT TIGHTENER) | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 3759986 | BUSHING | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 3272476 | 10 SPRING AS | 1 | |
| 3337318 | 11 ADAPTER-FAN | 1 | |
| 3337319 | 12 PULLEY-FAN (3-GROOVE) | 1 | |
| 3337334 | 13 BRACKET AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 1S8687 | 15 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 2S6151 | 16 GASKET | 1 | |
| 2S6160 | 17 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 3B4617 | 18 PIN-COTTER | 2 | |
| 4M6425 | 19 BOLT (5/16-18X1-IN) | 4 | |
| 4S5882 | 20 BOLT (1/2-13X7.25-IN) | 1 | |
| 5M9735 | 21 SEAL-LIP TYPE | 1 | |
| 5P2566 | 22 BOLT (1/2-13X1.5-IN) | 6 | |
| 5S7379 | 23 BOLT (3/8-16X0.875-IN) | 1 | |
| 5S7382 | 24 BOLT (3/8-16X1.375-IN) | 6 | |
| 6B1124 | 25 BALL BEARING | 2 | |
| 6N6651 | 26 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 6V4432 | 27 BOLT (1/2-13X4-IN) | 4 | |
| 6V8188 | 28 NUT (1/2-13-THD) | 1 | |
| 6W5752 | 29 PIN | 2 | |
| 7X0337 | 30 BOLT (1/2-13X5.75-IN) | 3 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 19 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4835 | 33 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T8919 | 35 BOLT (1/2-13X1.75-IN) | 2 |
