System And Components
295-5248 DRIVE GP-FANS/N MWH1-UP
Group No: 295-5248
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 2S6150 | 2 COVER-PULLEY | 1 | |
| 3H0120 | 3 ELBOW | 1 | |
| 6N3641 | 4 PULLEY-TIGHTENER | 1 | |
| 6U1989 | 5 VALVE-RELIEF | 1 | |
| 8B2327 | 6 RING-RETAINING | 1 | |
| 8N5579 | 7 RETAINER | 1 | |
| 2862216 | 8 BRACKET AS | 1 | |
| 3158203 | 9 BRACKET | 1 | |
| 3158206 | 10 PULLEY-CRANKSHAFT (3-GROOVE) | 1 | |
| 3158208 | 11 ADAPTER-FAN | 1 | |
| 3225108 | 12 ARM AS (BELT TIGHTENER) | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 3759986 | BUSHING | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 3272476 | 13 SPRING AS | 1 | |
| 3337319 | 14 PULLEY-FAN (3-GROOVE) | 1 | |
| 3337334 | 15 BRACKET AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 3343974 | 16 HUB-FAN PULLEY | 1 | |
| 3356140 | 17 HOSE AS | 1 | |
| 3436391 | 18 ADAPTER AS | 1 | |
| 1W5075 | SHAFT-FAN | 1 | |
| 2D6642 | BALL | 1 | |
| 0S0509 | 19 BOLT (3/8-16X0.75-IN) | 1 | |
| 1860359 | 20 CLIP | 1 | |
| 1D4624 | 21 BOLT (3/4-10X9-IN) | 1 | |
| 1S8687 | 22 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 1T0210 | 23 BALL BEARING | 2 | |
| 2S6151 | 24 GASKET | 1 | |
| 2S6160 | 25 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 3B4617 | 26 PIN-COTTER | 2 | |
| 3B8489 | 27 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 4M6425 | 28 BOLT (5/16-18X1-IN) | 4 | |
| 4S5882 | 29 BOLT (1/2-13X7.25-IN) | 1 | |
| 5F3144 | 30 SEAL-O-RING | 1 | |
| 5K5959 | 31 SEAL-O-RING | 1 | |
| 5M9735 | 32 SEAL-LIP TYPE | 1 | |
| 5P5299 | 33 SEAL-LIP TYPE | 1 | |
| 5S7379 | 34 BOLT (3/8-16X0.875-IN) | 1 | |
| 5S7383 | 35 BOLT (3/8-16X1.75-IN) | 12 | |
| 6B1124 | 36 BALL BEARING | 2 | |
| 6N6651 | 37 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 6V4432 | 38 BOLT (1/2-13X4-IN) | 4 | |
| 6V8188 | 39 NUT (1/2-13-THD) | 1 | |
| 6W5752 | 40 PIN | 2 | |
| 7X0337 | 41 BOLT (1/2-13X5.75-IN) | 3 | |
| 7X7730 | 42 PLUG-PIPE | 1 | |
| 8N9765 | 43 SPACER (52X70X66-MM THK) | 1 | |
| 8N9766 | 44 SPACER | 1 | |
| 8N9768 | 45 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 8T4223 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 8T4224 | 47 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4835 | 48 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 8T8919 | 50 BOLT (1/2-13X1.75-IN) | 2 |
