System And Components
526-2137 DRIVE GP-FAN -VARIABLE SPEEDS/N MWH423-UP
Group No: 526-2137
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S6150 | 1 COVER-PULLEY | 1 | |
| 6N3641 | 2 PULLEY-TIGHTENER | 1 | |
| 6N6651 | 3 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 8N5579 | 4 RETAINER | 1 | |
| 8T6466 | 5 BOLT (M10X1.5X60-MM) | 8 | |
| 3158203 | 6 BRACKET | 1 | |
| 3158206 | 7 PULLEY-CRANKSHAFT (3-GROOVE) | 1 | |
| 3225108 | 8 ARM AS (BELT TIGHTENER) | 1 | |
| 4S5367 | 8A BUSHING AS (MOUNT) | 1 | |
| 3759986 | BUSHING | 1 | |
| 4N0955 | DOWEL | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 3272476 | 9 SPRING AS | 1 | |
| 3337319 | 10 PULLEY-FAN (3-GROOVE) | 1 | |
| 3337334 | 11 BRACKET AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 4550172 | 12 SPACER-FAN | 1 | |
| 5139272 | 13 DRIVE GP-FAN | 1 | |
| 5163853 | 14 SPIDER AS-FAN (8-BLADE) | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 1 | |
| 1156433 | 16 WASHER (11X50X6-MM THK) | 1 | |
| 1984777 | 17 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 1S8687 | 18 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 2S6151 | 19 GASKET | 1 | |
| 2S6160 | 20 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 3B4617 | 21 PIN-COTTER | 2 | |
| 4M6425 | 22 BOLT (5/16-18X1-IN) | 4 | |
| 4S5882 | 23 BOLT (1/2-13X7.25-IN) | 1 | |
| 5M9735 | 24 SEAL-LIP TYPE | 1 | |
| 8T4835 | 25 BOLT (1/2-13X2-IN) | 2 | |
| 5S7382 | 26 BOLT (3/8-16X1.375-IN) | 7 | |
| 6B1124 | 27 BALL BEARING | 2 | |
| 6V4432 | 28 BOLT (1/2-13X4-IN) | 4 | |
| 6V8188 | 29 NUT (1/2-13-THD) | 1 | |
| 6W5752 | 30 PIN | 2 | |
| 7X0339 | 31 BOLT (1/2-13X6.25-IN) | 3 | |
| 7X3391 | 32 WASHER-HARD (13.5X32X6-MM THK) | 2 | |
| 7X7729 | 33 WASHER (11X25X3-MM THK) | 8 | |
| 8B2327 | 34 RING-RETAINING | 1 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4896 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T7971 | 38 WASHER-HARD (13.5X25.5X5-MM THK) | 5 | |
| 5P2566 | 39 BOLT (1/2-13X1.5-IN) | 2 |
