System And Components
526-2138 DRIVE GP-FAN -DIRECT DRIVES/N MWH1-UP
Group No: 526-2138
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0509 | 1 BOLT (3/8-16X0.75-IN) | 1 | |
| 1D4624 | 2 BOLT (3/4-10X9-IN) | 1 | |
| 2S6150 | 3 COVER-PULLEY | 1 | |
| 3B8489 | 4 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3H0120 | 5 ELBOW | 1 | |
| 4L9337 | 6 BOLT (3/8-16X1.5-IN) | 6 | |
| 5P2424 | 7 BOLT (1/2-13X2.25-IN) | 2 | |
| 6N3641 | 8 PULLEY-TIGHTENER | 1 | |
| 6N6651 | 9 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 6U1989 | 10 VALVE-RELIEF | 1 | |
| 6V4432 | 11 BOLT (1/2-13X4-IN) | 4 | |
| 6V8188 | 12 NUT (1/2-13-THD) | 1 | |
| 7X0339 | 13 BOLT (1/2-13X6.25-IN) | 3 | |
| 8N5579 | 14 RETAINER | 1 | |
| 8N9765 | 15 SPACER (52X70X66-MM THK) | 1 | |
| 8N9766 | 16 SPACER | 1 | |
| 8N9768 | 17 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 8T2501 | 18 BOLT (3/8-16X2-IN) | 6 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4835 | 22 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 1156433 | 24 WASHER (11X50X6-MM THK) | 1 | |
| 1984777 | 25 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2862216 | 26 BRACKET AS | 1 | |
| 3158203 | 27 BRACKET | 1 | |
| 3158206 | 28 PULLEY-CRANKSHAFT (3-GROOVE) | 1 | |
| 3158208 | 29 ADAPTER-FAN | 1 | |
| 3225108 | 30 ARM AS (BELT TIGHTENER) | 1 | |
| 4S5367 | 30A BUSHING AS (MOUNT) | 1 | |
| 3759986 | BUSHING | 1 | |
| 4N0955 | DOWEL | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 3272476 | 31 SPRING AS | 1 | |
| 3337319 | 32 PULLEY-FAN (3-GROOVE) | 1 | |
| 3337334 | 33 BRACKET AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 3343974 | 34 HUB-FAN PULLEY | 1 | |
| 3356140 | 35 HOSE AS | 1 | |
| 3368878 | 36 SPIDER AS-FAN (8-BLADE) | 1 | |
| 3436391 | 37 ADAPTER AS | 1 | |
| 1W5075 | SHAFT-FAN | 1 | |
| 2D6642 | BALL | 1 | |
| 1860359 | 38 CLIP | 1 | |
| 1S8687 | 39 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 1T0210 | 40 BALL BEARING | 2 | |
| 2S6151 | 41 GASKET | 1 | |
| 2S6160 | 42 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 3B4617 | 43 PIN-COTTER | 2 | |
| 4M6425 | 44 BOLT (5/16-18X1-IN) | 4 | |
| 4S5882 | 45 BOLT (1/2-13X7.25-IN) | 1 | |
| 5F3144 | 46 SEAL-O-RING | 1 | |
| 5K5959 | 47 SEAL-O-RING | 1 | |
| 5M9735 | 48 SEAL-LIP TYPE | 1 | |
| 5P5299 | 49 SEAL-LIP TYPE | 1 | |
| 5S7382 | 50 BOLT (3/8-16X1.375-IN) | 1 | |
| 6B1124 | 51 BALL BEARING | 2 | |
| 6W5752 | 52 PIN | 2 | |
| 7X3391 | 53 WASHER-HARD (13.5X32X6-MM THK) | 6 | |
| 7X7729 | 54 WASHER (11X25X3-MM THK) | 6 | |
| 8B2327 | 55 RING-RETAINING | 1 | |
| 8T7971 | 56 WASHER-HARD (13.5X25.5X5-MM THK) | 5 |
