295-5215 AIR CLEANER GPS/N MWH1-UP

Group No: 295-5215
Part NumberPart NameQty
4W58281 CAP-AIR CLEANER2
7S11312 HOSE-ADAPTER4
9N07203 ELBOW-AIR INLET2
24274064 HOSE2
32250995 MANIFOLD AS1
33373386 BRACKET AS1
8T3597NUT-WELD (M12X1.75-THD)2
33561457 TUBE1
33561518 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)6
33614789 PLATE1
336148210 TUBE1
336148811 TUBE1
336149312 BRACKET AS1
336149513 TUBE AS1
343675914 BRACKET1
370626115 AIR CLEANER GP1
432622316 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
198477817 WASHER-HARD (13.5X30X12-MM THK)6
198478018 WASHER-HARD (17.5X32X8-MM THK)4
2W971019 MOUNT AS4
316048820 SPACER (11X25X78-MM THK)3
329355521 CLIP-HALF2
5P107622 WASHER-HARD (13.5X30X4-MM THK)2
5S738223 BOLT (3/8-16X1.375-IN)4
7X060324 WASHER-HARD (9.9X35X2.5-MM THK)4
8T412125 WASHER-HARD (11X21X2.5-MM THK)10
8T413726 BOLT (M10X1.5X20-MM)7
8T418327 BOLT (M12X1.75X40-MM)2
8T419228 BOLT (M12X1.75X25-MM)6
8T422229 WASHER-PLATED (11X32X2.5-MM THK)6
8T422330 WASHER-HARD (13.5X25.5X3-MM THK)6
8T477931 BOLT (M16X2X35-MM)4
8T543632 BOLT (M10X1.5X130-MM)3
8T498833 CLAMP-HOSE16
7X772934 WASHER (11X25X3-MM THK)2
8T413335 NUT (M10X1.5-THD)1
8T418536 BOLT (M10X1.5X50-MM)1
136419037 CLIP-2 PIECE1
136419138 CLIP-2 PIECE1
8T418439 BOLT (M12X1.75X45-MM)6
