System And Components
347-3725 SHIELD GP-EXHAUST -HIGH DEBRISS/N MDB1-UP
Group No: 347-3725
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270366 | 1 SPACER (11X32X24-MM THK) | 1 | |
| 3353524 | 2 SHIELD AS | 1 | |
| 3353525 | 3 SHIELD AS | 1 | |
| 3353526 | 4 SHIELD AS | 1 | |
| 3470056 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1W2431 | 6 CLAMP-BAND | 1 | |
| 6V1820 | 7 BOLT (M10X1.5X30-MM) | 1 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4185 | 11 BOLT (M10X1.5X50-MM) | 1 |
