System And Components
547-8155 LINES GP-SERVICE BRAKES/N SPD1-UP
Group No: 547-8155
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1076 | 1 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 6C3241 | 2 BOLT (1/2-13X1.5-IN) | 1 | |
| 5U2673 | 3 SPACER (11X25X40-MM) | 1 | |
| 6G1444 | 4 ADAPTER | 1 | |
| 8T4224 | 5 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T8901 | 6 TEE-O-RING PORT | 2 | |
| 1595740 | 7 HOSE | 2 | |
| 2352478 | 8 SEAL-RECTANGULAR | 1 | |
| 2636342 | 9 CLIP | 2 | |
| 2815972 | 10 CONNECTOR AS | 3 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2815978 | 11 CONNECTOR AS | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3003905 | 12 ACCUMULATOR GP-BRAKE (CHARGED) | 1 | |
| 3196211 | 13 ADAPTER AS | 2 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196216 | 14 CONNECTOR AS | 2 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3218616 | 15 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3289816 | 16 CONNECTOR AS | 1 | |
| 1087251 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3295528 | 17 ELBOW AS | 1 | |
| 8T8899 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 3537367 | 18 CLIP | 1 | |
| 3656133 | 19 STUD-TAPERLOCK (M12X1.75X110-MM) | 1 | |
| 3893725 | 20 ELBOW AS | 1 | |
| 8T0404 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3960429 | 21 PLUG AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603693 | PLUG (3/4-16-THD) | 1 | |
| 3985602 | 22 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603694 | PLUG | 1 | |
| 3997920 | 23 FILTER GP-OIL (BRAKE CHARGE) | 1 | |
| 4158651 | 24 FLANGE | 2 | |
| 4520432 | 25 ADAPTER AS | 3 | |
| 6V0301 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4520434 | 26 TEE AS | 1 | |
| 6V9846 | TEE | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 4699340 | 27 CLAMP | 2 | |
| 4755008 | 28 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3218637 | 29 ADAPTER AS | 1 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 5387768 | 30 VALVE GP-BRAKE CONTROL | 1 | |
| 5416911 | 31 PLATE AS | 1 | |
| 2284710 | SPACER (13.8X30X20-MM THK) | 6 | |
| 5418530 | 32 HOSE AS | 1 | |
| 5418537 | 33 TUBE AS | 1 | |
| 5418538 | 34 TUBE AS | 1 | |
| 5418539 | 35 TUBE AS | 1 | |
| 5418613 | 36 BRACKET | 1 | |
| 5433518 | 37 HOSE AS | 1 | |
| 5433519 | 38 HOSE AS | 1 | |
| 5443119 | 39 VALVE GP-CHARGING | 1 | |
| 4230507 | VALVE GP-RELIEF | 1 | |
| 5444479 | 40 HOSE AS | 1 | |
| 5478256 | 41 HOSE AS | 1 | |
| 5478257 | 42 HOSE AS | 1 | |
| 5778957 | 43 BRACKET AS | 1 | |
| 5478259 | 44 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 5478260 | 45 HOSE AS | 1 | |
| 5478261 | 46 HOSE AS | 1 | |
| 5478262 | 47 HOSE AS | 1 | |
| 5478263 | 48 HOSE AS | 1 | |
| 5478264 | 49 PLATE | 1 | |
| 5478265 | 50 HOSE AS | 1 | |
| 5478266 | 51 TUBE AS | 1 | |
| 5478267 | 52 TUBE | 1 | |
| 5478268 | 53 TUBE AS | 1 | |
| 5481309 | 54 HOSE AS | 1 | |
| 5489678 | 55 HOSE AS | 1 | |
| 1705715 | 56 SEAL-O-RING | 1 | |
| 1984778 | 57 WASHER-HARD (13.5X30X12-MM THK) | 24 | |
| 1S0994 | 58 CLIP (LOOP) | 1 | |
| 2006345 | 59 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 60 STRAP-CABLE | 2 | |
| 2154013 | 61 CLAMP | 8 | |
| 2287092 | 62 SEAL-O-RING | 8 | |
| 2287093 | 63 SEAL-O-RING | 1 | |
| 2352477 | 64 SEAL-RECTANGULAR | 2 | |
| 2385080 | 65 SEAL-O-RING | 1 | |
| 2385082 | 66 SEAL-O-RING | 3 | |
| 2385084 | 67 SEAL-O-RING | 1 | |
| 2625492 | 69 FITTING-ELBOW | 1 | |
| 2815871 | 70 ADAPTER | 1 | |
| 2815933 | 71 ELBOW AS | 4 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815979 | 72 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2884403 | 73 STUD-TAPERLOCK (M10X1.5X85-MM) | 1 | |
| 2993424 | 74 WASHER-HARD (17.5X30X6-MM THK) | 1 | |
| 3023908 | 75 SPACER (11X20X30-MM THK) | 1 | |
| 3196221 | 76 ELBOW AS | 4 | |
| 6V9182 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196246 | 77 TEE AS | 1 | |
| 6V8777 | TEE-FACE SEAL | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218661 | 78 ELBOW | 1 | |
| 3291681 | 79 CLIP | 2 | |
| 3293356 | 80 NUT (M12X1.75-THD) | 7 | |
| 3295526 | 81 UNION AS | 1 | |
| 6V8996 | UNION | 1 | |
| 2287091 | SEAL-O-RING | 2 | |
| 3410103 | 82 CONNECTOR | 1 | |
| 3445674 | 83 NUT (M8X1.25-THD) | 3 | |
| 3445675 | 84 NUT (M10X1.5-THD) | 2 | |
| 3P1155 | 85 SEAL-O-RING | 1 | |
| 3P2404 | 86 CLIP | 2 | |
| 4L3641 | 87 CLIP | 1 | |
| 5P7466 | 88 CLIP (SLOT) | 12 | |
| 5P7467 | 89 CLIP (TAB) | 12 | |
| 5P7468 | 90 CLIP (SLOT) | 1 | |
| 5P7469 | 91 CLIP (TAB) | 1 | |
| 5P7470 | 92 CLIP (SLOT) | 1 | |
| 5P7471 | 93 CLIP (TAB) | 1 | |
| 5P7703 | 94 GROMMET (52-MM ID) | 1 | |
| 5P8112 | 95 GROMMET | 12 | |
| 5P8211 | 96 SEAL-O-RING | 1 | |
| 5P8444 | 97 GROMMET (37-MM ID) | 1 | |
| 6D4244 | 98 CLIP (LOOP) | 3 | |
| 6D4636 | 99 CLIP (LOOP) | 1 | |
| 6G6917 | 100 ADAPTER-PORT | 1 | |
| 6V1889 | 101 CLIP (LOOP) | 5 | |
| 6V4590 | 102 SEAL-O-RING | 1 | |
| 6V9170 | 103 NUT-BULKHEAD (1-14-THD) | 1 | |
| 1P4577 | 104 FLANGE-HALF | 2 | |
| 8T0439 | 105 BOLT-SOCKET HEAD (M16X2X30-MM) | 8 | |
| 8T4121 | 106 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4133 | 107 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 108 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 109 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4139 | 110 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4184 | 111 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4194 | 112 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4196 | 113 BOLT (M10X1.5X35-MM) | 9 | |
| 8T4223 | 114 WASHER-HARD (13.5X25.5X3-MM THK) | 29 | |
| 8T4910 | 115 BOLT (M12X1.75X60-MM) | 7 | |
| 8T4956 | 116 BOLT (M12X1.75X35-MM) | 2 | |
| 8T8920 | 117 BOLT (1/2-13X3.25-IN) | 2 | |
| 5588697 | 118 HOSE AS | 1 | |
| 9X6000 | 119 BOLT (M8X1.25X180-MM) | 3 | |
| 9X8250 | 120 CLIP (LOOP) | 4 | |
| 7X0584 | 121 WASHER-HARD (13.5X20.5X2-MM THK) | 1 | |
| 1642108 | 122 WASHER (13.03X25.4X2.38-MM THK) | 1 | |
| 4934395 | 123 FILM-IDENTIFICATION (BRAKE OIL FILTER) | 1 | |
| 3410084 | 124 CONNECTOR AS | 2 | |
| 3E7412 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2287090 | 125 SEAL-O-RING | 4 | |
| 5S7382 | 126 BOLT (3/8-16X1.375-IN) | 4 | |
| 8C4436 | 127 BOLT (1/2-13X1.375-IN) | 4 | |
| 8T4896 | 128 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9S1366 | 129 BOLT (1/2-13X2.5-IN) | 2 | |
| 8T4183 | 130 BOLT (M12X1.75X40-MM) | 8 | |
| 5P8245 | 131 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1S2174 | 132 SEAL-O-RING | 1 | |
| 0S1587 | 133 BOLT (1/2-13X1.75-IN) | 2 | |
| 4227706 | KIT-REPAIR (VALVE) | 1 | |
| 4230508 | KIT-REPAIR (VALVE) | 1 |
