System And Components
235-4023 MUFFLER GPS/N F7D1-UP
Group No: 235-4023
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0919035 | 1 SPACER (11X25X20-MM THK) | 3 | |
| 2473401 | 2 GUARD AS | 1 | |
| 2473402 | 3 PLATE AS | 1 | |
| 2473403 | 4 BRACKET | 1 | |
| 2473406 | 5 TUBE AS | 1 | |
| 2473408 | 6 MUFFLER AS | 1 | |
| 2477593 | 7 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2834945 | 8 GUARD AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1318881 | 9 CLAMP AS | 1 | |
| 7X7729 | 10 WASHER (11X25X3-MM THK) | 12 | |
| 7Y1727 | 11 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4186 | 14 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 18 NUT (M12X1.75-THD) | 2 | |
| 9N1941 | 19 CLAMP-V BAND | 1 | |
| 9F2247 | 20 PLUG-PIPE (1/8-27-THD) | 1 |
