System And Components
474-2107 ACCESSORY & FAN DRIVE GPS/N TXD1-UP; THX1-UP
Group No: 474-2107
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1117238 | 1 PLATE (THRUST) | 1 | |
| 1892449 | 2 SUPPORT | 1 | |
| 1903968 | 3 SHAFT-FAN | 1 | |
| 4857138 | 4 BELT-SERPENTINE | 1 | |
| 2222880 | 5 BELT TENSIONER | 1 | |
| 5363602 | 6 BRACKET | 1 | |
| 2285827 | 7 RETAINER-BEARING | 1 | |
| 2432310 | 8 COVER | 1 | |
| 3079798 | 9 BEARING AS | 1 | |
| 3331207 | 10 IDLER AS | 1 | |
| 3630255 | 11 PULLEY-FAN | 1 | |
| 4863152 | 12 SUPPORT AS | 1 | |
| 5V9221 | SPACER (13.8X25X25-MM THK) | 1 | |
| 5C7423 | 13 SCREW (M6X1X16-MM) | 4 | |
| 6V3940 | 14 BOLT (M8X1.25X25-MM) | 7 | |
| 6V5218 | 15 BOLT (M8X1.25X35-MM) | 2 | |
| 6V5219 | 16 BOLT (M8X1.25X40-MM) | 2 | |
| 6V5839 | 17 WASHER (11X21X2.5-MM THK) | 7 | |
| 6V5842 | 18 BOLT (M10X1.5X40-MM) | 6 | |
| 8T0643 | 19 BOLT (M10X1.5X80-MM) | 1 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 9 |
