System And Components
372-3160 MUFFLER GPS/N F7B1-UP
Group No: 372-3160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N1941 | 1 CLAMP-V BAND | 1 | |
| 2059880 | 2 MUFFLER AS | 1 | |
| 3723156 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 2 | |
| 3723157 | 4 GUARD AS | 1 | |
| 3723161 | 5 PIPE AS | 1 | |
| 3923542 | 6 COVER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3923543 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 0919035 | 8 SPACER (11X25X20-MM THK) | 3 | |
| 3887016 | 9 CLAMP-BENT BOLT | 1 | |
| 7X0310 | 11 BOLT (7/16-14X2-IN) | 4 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 9 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 7 | |
| 8T5360 | 20 WASHER (12X22.5X2.5-MM THK) | 4 |
