System And Components
Assembly
100%

339-6605 FRAME GP-UPPERS/N F7B276-306

Group No: 339-6605
Part NumberPart NameQty
5U61811 PAD1
7Y16472 GASKET1
7Y24983 SHIM (1.6-MM THK)1
7Y33554 SHIM (1.6-MM THK)2
08745875 GROMMET3
09300836 SHIM (1-MM THK)1
09300907 SHIM (1-MM THK)2
09301158 SHIM (2-MM THK)1
09301229 SHIM (2-MM THK)2
107315710 WASHER (22X76.2X6-MM THK)2
212802011 PLATE3
212802412 PIN AS1
212808513 PIN AS1
214783314 GUARD AS1
8T3612NUT-WELD (M8X1.25-THD)2
214783515 STRIP1
445262116 GUARD1
361529217 GUARD1
362388218 HANDLE AS1
362388319 HANDLE AS1
363014020 FRAME AS1
363015721 PLATE1
363015822 PLATE1
093036423 SPACER (103X140X12-MM THK)1
095130224 DOWEL1
148501825 GROMMET2
6V823726 WASHER (26X44X4-MM THK)38
7X255327 BOLT (M16X2X40-MM)18
7Y164828 STRIP1
7Y816529 GROMMET2
7Y816730 GROMMET (50-MM ID)1
8T066931 BOLT (M24X3X130-MM)32
141637332 BOLT (M24X3X150-MM)6
8T412133 WASHER-HARD (11X21X2.5-MM THK)23
8T412334 WASHER (22X35X3.5-MM THK)2
8T413335 NUT (M10X1.5-THD)2
8T413636 BOLT (M10X1.5X25-MM)13
8T413937 BOLT (M12X1.75X30-MM)4
8T419538 BOLT (M10X1.5X30-MM)8
8T422339 WASHER-HARD (13.5X25.5X3-MM THK)4
8T478040 BOLT (M20X2.5X30-MM)2
9X825741 WASHER (17.5X30X3.5-MM THK)18
5P830942 SEAL (3-M)
202400443 GROMMET1
445169144 PLATE1
212802145 PLATE2
8T422446 WASHER-HARD (8.8X16X2-MM THK)2
8T418947 BOLT (M8X1.25X20-MM)2
