339-6605 FRAME GP-UPPERS/N F7C277-UP

Group No: 339-6605
Part NumberPart NameQty
5U61811 PAD1
7Y16472 GASKET1
7Y24983 SHIM (1.6-MM THK)1
7Y33554 SHIM (1.6-MM THK)2
08745875 GROMMET3
09300836 SHIM (1-MM THK)1
09300907 SHIM (1-MM THK)2
09301158 SHIM (2-MM THK)1
09301229 SHIM (2-MM THK)2
107315710 WASHER (22X76.2X6-MM THK)2
212802011 PLATE2
212802412 PIN AS1
212808513 PIN AS1
453424414 GUARD AS1
453341915 FLAP1
445262116 GUARD1
361529217 GUARD1
362388218 HANDLE AS1
362388319 HANDLE AS1
363014020 FRAME AS1
363015721 PLATE1
363015822 PLATE1
093036423 SPACER (103X140X12-MM THK)1
095130224 DOWEL1
148501825 GROMMET2
6V823726 WASHER (26X44X4-MM THK)38
7X255327 BOLT (M16X2X40-MM)27
7Y164828 STRIP1
7Y816529 GROMMET2
7Y816730 GROMMET (50-MM ID)1
8T066931 BOLT (M24X3X130-MM)32
141637332 BOLT (M24X3X150-MM)6
8T412133 WASHER-HARD (11X21X2.5-MM THK)23
8T412334 WASHER (22X35X3.5-MM THK)2
8T413335 NUT (M10X1.5-THD)2
8T413636 BOLT (M10X1.5X25-MM)13
8T413937 BOLT (M12X1.75X30-MM)6
8T419538 BOLT (M10X1.5X30-MM)8
8T422339 WASHER-HARD (13.5X25.5X3-MM THK)6
8T478040 BOLT (M20X2.5X30-MM)2
9X825741 WASHER (17.5X30X3.5-MM THK)27
5P830942 SEAL (2.6-M)
202400443 GROMMET1
445169144 PLATE1
212802145 PLATE2
7X057946 WASHER-HARD (8.8X25.5X2-MM THK)4
8T754747 BOLT (M8X1.25X30-MM)4
453341848 FLAP1
453341549 GUARD AS1
7M451450 CORK1
493469451 PLATE1
493469552 PLATE1
510679353 PLATE1
9X261654 SCREW-SOCKET (M8X1.25X16-MM)6
370161455 PLATE3
1U8846SEALANT-GASKET
