Assembly
100%

379-5857 BOOM GPS/N F7C1-UP

Group No: 379-5857
Part NumberPart NameQty
7Y24981 SHIM (1.6-MM THK)2
7Y33552 SHIM (1.6-MM THK)2
09300833 SHIM (1-MM THK)2
09300904 SHIM (1-MM THK)2
09301155 SHIM (2-MM THK)2
09301226 SHIM (2-MM THK)2
10731577 WASHER (22X76.2X6-MM THK)3
51836608 BELT1
21280809 GUARD-DEBRIS (RUBBER, FRONT)1
212808210 WASHER-SPECIAL1
212808511 PIN AS2
212808612 COLLAR2
212808713 GROMMET2
212809014 TUBE AS1
212809215 PLATE2
212809716 PIN AS1
228669017 SPACER (103X140X12-MM THK)1
392764118 BOOM & BEARING AS1
7Y239718A BUSHING2
1129073STUD-WELD (M12X1.75X21.1-MM)2
1175604STUD (M10X1.5X23-MM)3
2128879BOSS (M20X2.5X25-MM)2
348765819 PLATE1
379586220 PLATE1
379586321 PLATE AS1
2J056422 LOCKNUT (2-12-THD)1
3B860323 SETSCREW-SOCKET2
8T412324 WASHER (22X35X3.5-MM THK)3
8T422325 WASHER-HARD (13.5X25.5X3-MM THK)22
8T424426 NUT (M12X1.75-THD)5
8T477827 LOCKNUT (M16X2-THD)2
8T478028 BOLT (M20X2.5X30-MM)3
8T495629 BOLT (M12X1.75X35-MM)14
8T638530 BOLT (M16X2X180-MM)2
166149631 SEAL-LIP TYPE2
9X825732 WASHER (17.5X30X3.5-MM THK)4
8T412133 WASHER-HARD (11X21X2.5-MM THK)4
8T413634 BOLT (M10X1.5X25-MM)4
442671335 GUARD AS1
8T419436 BOLT (M12X1.75X50-MM)3
463102037 PLATE AS1
518011538 BRACKET AS1
