System And Components
198-0030 LINES GP-TURBOCHARGER OILS/N TX71-UP; KHX12897-UP
Group No: 198-0030
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W3484 | 1 SPACER (9X18X30-MM THK) | 1 | |
| 1876294 | 2 HOSE AS-OIL SUPPLY | 1 | |
| 2466036 | 3 HOSE | 1 | |
| 2501424 | 4 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2608630 | 5 TUBE AS-DRAIN | 1 | |
| 2608631 | 6 TUBE AS-DRAIN | 1 | |
| 1833399 | 7 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1978419 | 8 GASKET (TURBOCHARGER) | 1 | |
| 2109246 | 9 SEAL-O-RING | 1 | |
| 2843502 | 10 CLAMP-BAND | 2 | |
| 3E4352 | 11 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 5P7970 | 12 NUT (M8X1.25-THD) | 1 | |
| 6V5218 | 13 BOLT (M8X1.25X35-MM) | 4 | |
| 8T0100 | 14 BOLT (M8X1.25X60-MM) | 1 | |
| 8T1889 | 15 CLIP (SLOT) | 1 | |
| 8T1890 | 16 CLIP (TAB) | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9M9840 | 18 CLIP | 1 |
