System And Components
283-6395 AIR COMPRESSOR GPS/N TWM1-UP
Group No: 283-6395
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7086 | 1 PLUG | 1 | |
| 6N7721 | 2 V-BELT (AIR COMPRESSOR) | 1 | |
| 6N8643 | 3 PULLEY-AIR COMPRESSOR (1-GROOVE) | 1 | |
| 6N9042 | 4 GASKET | 1 | |
| 1228966 | 5 AIR COMPRESSOR GP | 1 | |
| 2836394 | 6 BRACKET AS | 1 | |
| 4S1994 | LUG | 1 | |
| 0S1608 | 7 BOLT (3/8-16X3.75-IN) | 2 | |
| 1314871 | 8 SUMP-COMPRESSOR | 1 | |
| 1982970 | 9 LOCKNUT (3/8-16-THD) | 5 | |
| 1B7182 | 10 BOLT (5/16-18X1.25-IN) | 3 | |
| 3B1915 | 11 BOLT (3/8-16X1.375-IN) | 1 | |
| 3B4618 | 12 PIN-COTTER | 1 | |
| 3S1546 | 13 NUT-FULL (7/16-14-THD) | 4 | |
| 4F5192 | 14 BOLT (7/16-14X3-IN) | 4 | |
| 4S9191 | 15 WASHER (12X22.5X5-MM THK) | 8 | |
| 5B4274 | 16 BOLT (3/8-16X3.5-IN) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 6N7705 | 18 ADAPTER | 1 | |
| 6V5101 | 19 SEAL-O-RING | 1 | |
| 9L4238 | 20 BOLT (3/8-16X8.5-IN) | 1 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 2 |
