System And Components
Assembly
100%

420-2871 LINES GP-AIR COMPRESSORS/N TWM1-UP

Group No: 420-2871
Part NumberPart NameQty
7W18391 HOSE AS1
11926042 TEE-O-RING1
12430193 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
16663224 BRACKET AS1
1F0750NUT-WELD (3/8-16-THD)1
25622135 HOSE AS1
34388886 GASKET1
35102607 ELBOW AS1
6V6609SEAL-O-RING1
0307943ELBOW1
35778688 HOSE AS1
39156249 COVER1
396584310 FLANGE-SPECIAL1
436821711 TUBE AS1
005065812 ELBOW-FLARED1
030814413 REDUCER-FLARED1
030831614 ELBOW1
0L135115 BOLT (3/8-16X0.875-IN)2
0L207016 BOLT (3/8-16X2.25-IN)1
0S050917 BOLT (3/8-16X0.75-IN)1
0S159018 BOLT (3/8-16X2-IN)1
0S159119 BOLT (3/8-16X1.5-IN)6
193829820 SPACER1
1C225121 BOLT (3/8-16X1.87-IN)2
1P144122 NUT-FLARED (3/4-16-THD)1
238508123 SEAL-O-RING1
238508224 SEAL-O-RING1
239557225 SEAL-INTEGRAL1
2P843026 CONNECTOR1
302390827 SPACER (11X20X30-MM THK)1
353795228 GROMMET1
353795329 GROMMET (19-MM ID)1
353795430 GROMMET (16-MM ID)1
381021231 CLAMP-HOSE2
3R538732 CONNECTOR1
4P723333 GROMMET2
5M289434 WASHER-HARD (10.2X18.5X2.5-MM THK)10
5P459235 ELBOW-FLARED1
6V182036 BOLT (M10X1.5X30-MM)1
6V506437 SEAL-O-RING1
6V583938 WASHER (11X21X2.5-MM THK)1
8M054739 ELBOW-FLARED (SWIVEL)1
8T188740 CLIP (SLOT)2
8T188841 CLIP (TAB)2
8T188942 CLIP (SLOT)2
8T189043 CLIP (TAB)2
8T189744 CLIP (SLOT)1
8T189845 CLIP (TAB)1
9M652246 CONNECTOR (1/2-14 NPTF)1
9X645847 WASHER-HARD (10.2X22.5X3-MM THK)3
319881548 HOSE (48-CM)
