System And Components
282-6854 LINES GP-TURBOCHARGER OILS/N TWM1-UP
Group No: 282-6854
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N7559 | 1 GASKET | 2 | |
| 7N9008 | 2 ELBOW | 2 | |
| 9M2564 | 3 CLAMP-TUBE | 4 | |
| 2826856 | 4 TUBE AS | 1 | |
| 2826858 | 5 TUBE AS | 1 | |
| 3072257 | 6 TUBE AS | 1 | |
| 3079207 | 7 TUBE AS | 1 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 2 | |
| 1123540 | 10 SEAL-O-RING | 2 | |
| 1488315 | 11 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 4 | |
| 3B1915 | 13 BOLT (3/8-16X1.375-IN) | 4 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P5846 | 15 SEAL-O-RING | 2 | |
| 7N8875 | 16 GASKET | 2 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 2 |
