System And Components
297-9896 LINES GP-TURBOCHARGER OILS/N TWM1-UP; PKZ1-UP
Group No: 297-9896
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K3215 | 1 BOSS (0.413X1X0.630-IN THK) | 1 | |
| 7N7559 | 2 GASKET | 2 | |
| 7N9008 | 3 ELBOW | 1 | |
| 9M2564 | 4 CLAMP-TUBE | 2 | |
| 2196014 | 5 TUBE AS | 1 | |
| 2395572 | 6 SEAL-INTEGRAL | 1 | |
| 2979897 | 7 TUBE AS-TURBOCHARGER OIL (LH) | 1 | |
| 2979898 | 8 TUBE AS-TURBOCHARGER OIL (FLEXIBLE) | 1 | |
| 3072257 | 9 TUBE AS | 1 | |
| 0S1571 | 10 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 3 | |
| 1123540 | 12 SEAL-O-RING | 1 | |
| 1488315 | 13 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488390 | 14 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 4 | |
| 1S0724 | 16 CLIP | 1 | |
| 2A4639 | 17 BOLT (3/8-16X1.625-IN) | 1 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 2 | |
| 4B9302 | 19 CLIP (LOOP) | 1 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P5846 | 21 SEAL-O-RING | 1 | |
| 7N8875 | 22 GASKET | 2 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
