System And Components
289-2037 LINES GP-TURBOCHARGER OILS/N TLD220-UP
Group No: 289-2037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N7559 | 1 GASKET | 2 | |
| 9M2564 | 2 CLAMP-TUBE | 4 | |
| 2892038 | 3 TUBE AS | 1 | |
| 2892039 | 4 TUBE AS | 1 | |
| 2892043 | 5 FLANGE | 2 | |
| 3072257 | 6 TUBE AS | 1 | |
| 3079207 | 7 TUBE AS | 1 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 2 | |
| 1488315 | 10 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 4 | |
| 1H9696 | 12 SEAL-O-RING | 2 | |
| 2A4639 | 13 BOLT (3/8-16X1.625-IN) | 4 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 7N8875 | 15 GASKET | 2 | |
| 8F4994 | 16 SEAL-O-RING | 2 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 2 |
