System And Components
297-9892 LINES GP-TURBOCHARGER OILS/N TLD1-222
Group No: 297-9892
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7G1239 | 1 SPACER (10.5X19X4.5-MM THK) | 1 | |
| 7N7559 | 2 GASKET | 2 | |
| 7N9008 | 3 ELBOW | 1 | |
| 7W6333 | 4 SPACER (10.5X20X10.7-MM THK) | 1 | |
| 2395572 | 5 SEAL-INTEGRAL | 1 | |
| 2826855 | 7 TUBE AS | 1 | |
| 2826857 | 8 TUBE AS | 1 | |
| 2979893 | 9 TUBE AS-TURBOCHARGER OIL (LH) | 1 | |
| 2979894 | 10 TUBE AS-TURBOCHARGER OIL (FLEXIBLE) | 1 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 3 | |
| 1123540 | 13 SEAL-O-RING | 1 | |
| 1488390 | 14 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 4 | |
| 1S0724 | 16 CLIP | 2 | |
| 3B1915 | 17 BOLT (3/8-16X1.375-IN) | 3 | |
| 4B9302 | 18 CLIP (LOOP) | 2 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P5846 | 20 SEAL-O-RING | 1 | |
| 7N8875 | 21 GASKET | 2 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 23 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
