System And Components
524-9401 LINES GP-TURBOCHARGER WATERS/N TLD1-UP
Group No: 524-9401
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0706 | 1 CLAMP AS | 2 | |
| 3078373 | GROMMET | 2 | |
| 7N7878 | 2 PLATE-COVER | 2 | |
| 1187809 | 3 PLATE | 1 | |
| 2777699 | 4 FLANGE | 2 | |
| 3419211 | 5 GASKET | 8 | |
| 3664677 | 6 TEE AS | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1808424 | SEAL-O-RING | 2 | |
| 4805511 | 7 BRACKET | 1 | |
| 5249399 | 8 HOSE AS | 1 | |
| 5269120 | 9 TUBE AS | 1 | |
| 5269121 | 10 TUBE AS | 1 | |
| 5275775 | 11 HOSE AS | 1 | |
| 5277224 | 12 TUBE AS | 1 | |
| 5277225 | 13 TUBE AS | 1 | |
| 5277226 | 14 TUBE AS | 1 | |
| 5277227 | 15 TUBE AS | 1 | |
| 5286872 | 16 BRACKET | 1 | |
| 5286873 | 17 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 0L1143 | 18 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 17 | |
| 1808424 | 20 SEAL-O-RING | 10 | |
| 2492943 | 21 STUD (3/8-16-THD) | 2 | |
| 2Y5829 | 22 NUT (M10X1.5-THD) | 1 | |
| 3537955 | 23 GROMMET | 1 | |
| 3537957 | 24 GROMMET | 5 | |
| 4W7627 | 25 SPACER (11X19X37-MM THK) | 1 | |
| 5B9603 | 26 BOLT (3/8-16X5-IN) | 5 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 6V5063 | 29 SEAL-O-RING | 1 | |
| 6V5839 | 30 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6609 | 31 SEAL-O-RING | 1 | |
| 6V8633 | 32 CONNECTOR | 1 | |
| 6V9002 | 33 ELBOW | 1 | |
| 6V9169 | 34 NUT (13/16-16-THD) | 2 | |
| 7X7715 | 35 TEE | 1 | |
| 8M9024 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 8T1887 | 37 CLIP (SLOT) | 6 | |
| 8T1888 | 38 CLIP (TAB) | 6 | |
| 8T6895 | 39 TEE-UNION | 1 | |
| 9S8752 | 41 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 3 |
