System And Components
355-1056 CONTROL GP-INLET AIRS/N E7B1-UP
Group No: 355-1056
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4704925 | 1 PLUG | 1 | |
| 3599666 | 3 BOLT-FLANGE HEAD (M8X1.25X130-MM) | 2 | |
| 3197840 | 4 GASKET (INLET ELBOW) | 1 | |
| 3496802 | 5 THROTTLE AS | 1 | |
| 5184611 | 6 BRACKET | 1 | |
| 3496805 | 7 PIPE-INLET | 1 | |
| 3545632 | 8 HOSE | 1 | |
| 3551079 | 9 CONNECTION | 1 | |
| 4795919 | 10 VALVE & MOUNTING GP (NRS) | 1 | |
| 1783336 | 11 NUT-HEX FLANGE (M8X1.25-THD) | 1 | |
| 3426268 | 12 STUD (M8X1.25X80-MM) | 1 | |
| 0358063 | 13 PLUG | 1 | |
| 1013895 | 14 BOLT (M8X1.25X35-MM) | 3 | |
| 1440367 | 15 CLAMP-HOSE | 2 | |
| 6I0917 | 16 BOLT (M6X1X25-MM) | 2 | |
| 3674226 | 17 VALVE-SOLENOID (WASTEGATE) | 1 | |
| 6I0456 | 18 BOLT (M8X1.25X45-MM) | 4 | |
| 6I0839 | 19 BOLT (M8X1.25X70-MM) | 2 |
