System And Components
345-3943 LINES GP-STEERINGS/N A7A1-UP
Group No: 345-3943
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M6102 | 1 PIPE | 1 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 7Y3729 | 3 FLANGE-SPECIAL | 1 | |
| 8F0492 | 4 SPACER (0.531X1.125X0.625-IN THK) | 8 | |
| 9U3430 | 5 HOSE AS | 1 | |
| 1087550 | 6 CLIP | 2 | |
| 1095816 | 7 ELBOW | 2 | |
| 1252706 | 8 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1419520 | 9 HOSE AS | 1 | |
| 1419521 | 10 HOSE AS | 1 | |
| 1434158 | 11 CLIP | 2 | |
| 1488443 | 12 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 1512680 | 13 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 1539624 | 14 PUMP GP-PISTON | 1 | |
| 1622127 | 15 TUBE AS | 1 | |
| 1622128 | 16 TUBE AS | 1 | |
| 1628455 | 17 HOSE AS | 1 | |
| 1635442 | 18 BRACKET AS | 1 | |
| 2169195 | 19 MANIFOLD | 2 | |
| 2521285 | 20 TUBE AS | 1 | |
| 2577804 | 21 TUBE AS | 1 | |
| 2941153 | 22 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 2941154 | 23 HOSE AS | 2 | |
| 3047716 | 24 SUPPORT AS | 4 | |
| 6V8149 | NUT (M12X1.75-THD) | 2 | |
| 3159202 | 25 HOSE AS | 1 | |
| 3159203 | 26 HOSE AS | 1 | |
| 3263803 | 27 MANIFOLD GP-HYDRAULIC | 1 | |
| 0858091 | 28 BOLT (M10X1.5X55-MM) | 8 | |
| 0969986 | 29 BOLT (M12X1.75X55-MM) | 4 | |
| 1488353 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488407 | 31 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1536236 | 32 REDUCER AS | 2 | |
| 6V8946 | REDUCER | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 33 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P3702 | 34 SEAL-RECTANGULAR | 2 | |
| 1P3703 | 35 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 36 SEAL-RECTANGULAR | 6 | |
| 1P4579 | 37 FLANGE-HALF | 4 | |
| 1P4584 | 38 FLANGE-HALF | 4 | |
| 1P5767 | 39 FLANGE-HALF | 4 | |
| 1S0994 | 40 CLIP (LOOP) | 1 | |
| 4J0524 | 41 SEAL-O-RING | 2 | |
| 4J5267 | 42 SEAL-O-RING | 6 | |
| 5F3106 | 43 SEAL-O-RING | 1 | |
| 5K9090 | 44 SEAL-O-RING | 2 | |
| 5P7466 | 45 CLIP (SLOT) | 4 | |
| 5P7467 | 46 CLIP (TAB) | 4 | |
| 5P7703 | 47 GROMMET (52-MM ID) | 1 | |
| 5P8112 | 48 GROMMET | 4 | |
| 6J2680 | 49 SEAL-O-RING | 2 | |
| 5P7470 | 50 CLIP (SLOT) | 1 | |
| 5P7471 | 51 CLIP (TAB) | 1 | |
| 6V9746 | 52 SEAL-O-RING | 3 | |
| 7X0584 | 53 WASHER-HARD (13.5X20.5X2-MM THK) | 8 | |
| 7X2549 | 54 BOLT (M12X1.75X100-MM) | 8 | |
| 8C3205 | 55 FLANGE-HALF | 6 | |
| 8C3451 | 56 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T4121 | 57 WASHER-HARD (11X21X2.5-MM THK) | 29 | |
| 8T4136 | 58 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4139 | 59 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 60 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4184 | 61 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4194 | 62 BOLT (M12X1.75X50-MM) | 14 | |
| 8T4195 | 63 BOLT (M10X1.5X30-MM) | 12 | |
| 8T4196 | 64 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4223 | 65 WASHER-HARD (13.5X25.5X3-MM THK) | 68 | |
| 8T4648 | 66 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 67 BOLT (M12X1.75X35-MM) | 8 | |
| 8T7338 | 68 BOLT (M16X2X45-MM) | 2 | |
| 9X6032 | 69 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 8 | |
| 9X8257 | 70 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 1654931 | 71 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8077 | ELBOW | 1 |
