System And Components
399-0209 INSULATION GP-HEATS/N TWZ1-UP
Group No: 399-0209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3675676 | 1 SHIELD-HEAT | 1 | |
| 3675678 | 2 SHIELD-HEAT | 1 | |
| 3675679 | 3 SHIELD-HEAT | 1 | |
| 3675680 | 4 SHIELD-HEAT | 1 | |
| 3675683 | 5 SHIELD-HEAT | 1 | |
| 3675684 | 6 SHIELD-HEAT | 1 | |
| 3675694 | 7 SHIELD-HEAT | 1 | |
| 3683921 | 8 BRACKET AS | 1 | |
| 3783216 | 9 BRACKET AS | 4 | |
| 3990207 | 10 SHIELD-HEAT | 1 | |
| 4322360 | 11 SHIELD-HEAT | 1 | |
| 4322361 | 12 SHIELD-HEAT | 1 | |
| 2089277 | 13 BOLT-FLANGE HEAD (M6X1X20-MM) | 10 | |
| 3055385 | 14 BOLT (M8X1.25X50-MM) | 4 | |
| 3118366 | 15 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 3193515 | 16 BOLT-FLANGE HEAD (M6X1X10-MM) | 64 |
