System And Components
347-5124 LINES GP-AFTERCOOLER AIRS/N TWZ1-UP
Group No: 347-5124
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 1 | |
| 2178946 | 2 ELBOW | 1 | |
| 2840671 | 3 CLAMP-BAND | 1 | |
| 3494612 | 4 ELBOW-AIR | 1 | |
| 3649893 | 5 ELBOW | 1 | |
| 4868459 | 6 HOSE | 1 | |
| 3732383 | 7 BRACKET AS | 1 | |
| 4335712 | 8 TUBE AS | 1 | |
| 4339519 | 9 TUBE | 1 | |
| 4339520 | 10 TUBE | 1 | |
| 1553624 | 11 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 2087448 | 12 CLAMP | 6 | |
| 2965807 | 13 CLAMP | 2 | |
| 7E8630 | 14 HOSE-AIR INLET | 2 | |
| 7L8255 | 15 CLAMP-TUBE | 2 | |
| 8C3089 | 16 SEAL-O-RING | 1 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4186 | 18 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 4 | |
| 2162211 | 20 CLAMP | 4 | |
| 4615747 | 21 ELBOW | 2 |
