System And Components
380-8478 LINES GP-TURBOCHARGER WATERS/N TXW1-UP
Group No: 380-8478
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 1 | |
| 7N7878 | 2 PLATE-COVER | 2 | |
| 2777699 | 3 FLANGE | 2 | |
| 3419211 | 4 GASKET | 4 | |
| 4343537 | 5 HOSE & TUBE AS | 1 | |
| 3831194 | 6 BRACKET AS | 1 | |
| 4264028 | 7 UNION AS | 1 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 8T0075 | CONNECTOR | 1 | |
| 4264112 | 8 ADAPTER AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 8M0506 | ADAPTER-O-RING | 1 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 2 | |
| 5045289 | 10 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3717174 | 11 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 1 | |
| 1A2029 | 13 BOLT (3/8-16X1.125-IN) | 8 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 8T1888 | 15 CLIP (TAB) | 1 | |
| 8T1887 | 16 CLIP (SLOT) | 1 |
