System And Components
312-3466 DRIVE GP-ACCESSORYS/N AMA711-UP
Group No: 312-3466
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7G7014 | 1 FLANGE | 1 | |
| 1243019 | 2 BRACKET AS | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1903635 | 3 PULLEY (8-GROOVE) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 4 | |
| 2661464 | 5 BELT-SERPENTINE | 2 | |
| 2721889 | 6 ALTERNATOR GP-CHARGING (24-VOLT, 150-AMPERE) | 1 | |
| 2731090 | 7 PULLEY | 1 | |
| 5073868 | 8 COMPRESSOR GP-REFRIGERANT | 1 | |
| 3355474 | 9 BRACKET | 1 | |
| 3357294 | 10 GUARD | 1 | |
| 3477963 | 11 TENSIONER-BELT | 1 | |
| 6V3830 | 12 SEAL-O-RING | 1 | |
| 7X0288 | 13 BOLT (3/8-16X1.625-IN) | 4 | |
| 7X0325 | 14 BOLT (1/2-13X2.5-IN) | 1 | |
| 7X0334 | 15 BOLT (1/2-13X5-IN) | 2 | |
| 7X2538 | 16 BOLT (M8X1.25X100-MM) | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4178 | 18 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4222 | 19 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T6685 | 23 BOLT (M10X1.5X110-MM) | 4 | |
| 8T9389 | 24 BOLT (1/2-13X2.75-IN) | 1 | |
| 9X2125 | 25 BOLT-LOCKING (M10X1.5X25-MM) | 4 | |
| 2551281 | 26 BOLT-FLANGE HEAD (M8X1.25X100-MM) | 2 |
