System And Components
352-6152 LINES GP-ENGINE OIL FILTERS/N WZH1-UP
Group No: 352-6152
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1116 | 1 BODY-BYPASS | 1 | |
| 4N0861 | 2 COVER | 1 | |
| 4N0865 | 3 GASKET | 1 | |
| 4N8411 | 4 TUBE-COOLER BYPASS | 1 | |
| 4N8770 | 5 ELBOW-COOLER OUTLET | 1 | |
| 9F6304 | 6 SPRING | 2 | |
| 1P1367 | 7 PLUNGER (RELIEF VALVE) | 2 | |
| 9W1686 | 8 SPACER | 1 | |
| 3780576 | 9 HOSE AS | 1 | |
| 3780575 | 10 HOSE AS | 1 | |
| 3627842 | 11 BRACKET AS | 1 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1585 | 13 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 10 | |
| 0S1595 | 15 BOLT (1/2-13X1.25-IN) | 2 | |
| 0S1608 | 16 BOLT (3/8-16X3.75-IN) | 1 | |
| 0T0065 | 17 BOLT (3/8-16X3.5-IN) | 1 | |
| 3574572 | 18 ADAPTER AS | 2 | |
| 0318759 | CONNECTOR | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 0617540 | 19 SEAL-O-RING | 3 | |
| 1123540 | 20 SEAL-O-RING | 2 | |
| 1F7958 | 21 NUT-FULL (1/2-13-THD) | 2 | |
| 1P4578 | 22 FLANGE-HALF | 4 | |
| 1135304 | 23 SEAL-O-RING | 3 | |
| 1833407 | 24 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3072673 | 25 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5P7892 | 27 BOLT-12 POINT HEAD (7/16-14X2.75-IN) | 4 | |
| 5P8068 | 28 SEAL-O-RING | 1 | |
| 5P8244 | 29 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6K3771 | 31 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 4 | |
| 7G3413 | 32 CLIP (SLOT) | 1 | |
| 3466393 | 33 GROMMET | 1 | |
| 7G3414 | 34 CLIP (TAB) | 1 |
