System And Components
348-3624 LINES GP-AIRS/N AMA1-520
Group No: 348-3624
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N9545 | 1 ELBOW | 2 | |
| 3355469 | 2 HOSE | 2 | |
| 3382270 | 3 BRACKET AS | 2 | |
| 3774484 | 4 TUBE | 1 | |
| 3774485 | 5 TUBE AS | 1 | |
| 8T4988 | 6 CLAMP-HOSE | 2 | |
| 2471925 | 7 CLAMP-T BOLT | 2 | |
| 2564448 | 8 CLAMP-T BOLT | 4 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 7W2033 | 10 CLIP (TAB) | 2 | |
| 7W2034 | 11 CLIP (SLOT) | 2 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4183 | 14 BOLT (M12X1.75X40-MM) | 2 |
