System And Components
348-3625 LINES GP-AIRS/N AMA1-573
Group No: 348-3625
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C3910 | 1 HOSE | 2 | |
| 1243019 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1270929 | 3 CLAMP-V BAND | 2 | |
| 1473150 | 4 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1862002 | 5 HOSE | 5 | |
| 2086135 | 6 CLIP (SLOT) | 4 | |
| 2086136 | 7 CLIP (TAB) | 4 | |
| 2178946 | 8 ELBOW | 1 | |
| 2178947 | 9 ELBOW | 1 | |
| 3357296 | 10 TUBE AS | 2 | |
| 3357298 | 11 TUBE | 1 | |
| 3382249 | 12 BRACKET AS | 1 | |
| 3382272 | 13 BRACKET AS | 1 | |
| 3637277 | 14 BRACKET AS | 1 | |
| 3637278 | 15 TUBE | 1 | |
| 3W2647 | 16 SPACER (13.5X30X10-MM THK) | 1 | |
| 4L9337 | 17 BOLT (3/8-16X1.5-IN) | 4 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6V5048 | 19 SEAL-O-RING | 2 | |
| 8C3089 | 20 SEAL-O-RING | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4133 | 22 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4186 | 24 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4196 | 25 BOLT (M10X1.5X35-MM) | 1 | |
| 9G8140 | 26 SPACER (10.5X25X15-MM THK) | 4 | |
| 9S8002 | 27 PLUG (7/16-20-THD) | 2 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 4 | |
| 9X2201 | 29 CLAMP-HOSE | 32 | |
| 1477109 | 30 HOSE | 1 |
