System And Components
348-3625 LINES GP-AIRS/N AMA574-UP
Group No: 348-3625
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 2 | |
| 4932532 | 2 HOSE | 3 | |
| 2178946 | 3 ELBOW | 1 | |
| 2178947 | 4 ELBOW | 1 | |
| 3259616 | 5 HOSE | 1 | |
| 3382272 | 6 BRACKET AS | 1 | |
| 3637278 | 7 TUBE | 1 | |
| 4434848 | 8 HOSE | 2 | |
| 4620459 | 9 TUBE | 1 | |
| 1984777 | 10 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 2086135 | 11 CLIP (SLOT) | 2 | |
| 2086136 | 12 CLIP (TAB) | 2 | |
| 2087448 | 13 CLAMP | 4 | |
| 3445675 | 14 NUT (M10X1.5-THD) | 1 | |
| 6V5048 | 15 SEAL-O-RING | 2 | |
| 8C3089 | 16 SEAL-O-RING | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4186 | 18 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 1 | |
| 9B7237 | 20 BOLT (3/8-16X1.25-IN) | 4 | |
| 9S8002 | 21 PLUG (7/16-20-THD) | 2 | |
| 9X2201 | 22 CLAMP-HOSE | 16 |
