System And Components
339-8933 LINES GP-AIR CONDITIONER -ROPS MOUNTEDS/N AMA692-UP
Group No: 339-8933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5V9221 | 1 SPACER (13.8X25X25-MM THK) | 1 | |
| 7K1181 | 2 STRAP-CABLE | 8 | |
| 1629728 | 3 BRACKET AS | 1 | |
| 2945076 | 4 PLATE AS | 1 | |
| 3270282 | 5 SEAL-INTEGRAL (1/2-IN) | 4 | |
| 3477252 | 6 BRACKET AS | 1 | |
| 3611249 | 7 HARNESS AS-HEATER & AIR COND | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 3E3383 | WEDGE-RECEPTACLE LOCK (6-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 3751713 | 8 HOSE AS | 1 | |
| 2L1224 | CAP-SEAL (HIGH SIDE) | 1 | |
| 1807180 | CORE-VALVE | 1 | |
| 3751714 | 9 HOSE AS | 1 | |
| 3E4052 | CAP-SEAL (HIGH SIDE CHARGE PORT) | 1 | |
| 3E4058 | VALVE AS (REFRIGERANT, HIGH SIDE) | 1 | |
| 5141017 | 10 BRACKET AS | 1 | |
| 0672551 | 11 CLIP | 2 | |
| 1783336 | 12 NUT-HEX FLANGE (M8X1.25-THD) | 4 | |
| 3398936 | 13 CLIP (LOOP) | 1 | |
| 4D7733 | 14 CLIP (LOOP) | 6 | |
| 4P7428 | 15 CLIP (LADDER) | 1 | |
| 6D4247 | 16 CLIP | 5 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 13 |
