System And Components
486-2980 LINES GP-TURBOCHARGER WATERS/N WZH1-UP
Group No: 486-2980
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4809767 | 1 BRACKET | 1 | |
| 5P5777 | 2 ADAPTER-O-RING | 1 | |
| 7N7878 | 3 PLATE-COVER | 4 | |
| 8N0590 | 4 CLIP | 2 | |
| 9M6871 | 5 CLAMP | 6 | |
| 1784917 | 6 CAP-PROTECTIVE | 1 | |
| 1939131 | 7 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2501448 | 8 CONNECTOR | 1 | |
| 3419211 | 9 GASKET | 8 | |
| 3650579 | 10 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3769134 | 11 BRACKET AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 1 | |
| 3779583 | 12 CONNECTOR | 1 | |
| 3790146 | 13 BRACKET AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3920802 | 14 CONNECTOR AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 4216160 | 15 TEE AS | 1 | |
| 8T6895 | TEE-UNION | 1 | |
| 1808424 | SEAL-O-RING | 3 | |
| 4216197 | 16 TEE AS | 1 | |
| 7X7715 | TEE | 1 | |
| 1808424 | SEAL-O-RING | 3 | |
| 4354164 | 17 HOSE AS-WATER | 1 | |
| 4356282 | 18 BRACKET AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 2 | |
| 4496125 | 19 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4809766 | 20 BRACKET | 1 | |
| 4809768 | 21 TUBE AS | 1 | |
| 4847559 | 22 HOSE AS | 1 | |
| 4847563 | 23 TUBE AS | 1 | |
| 4847564 | 24 TUBE AS | 1 | |
| 4914097 | 25 TUBE AS | 1 | |
| 4914098 | 26 TUBE AS | 1 | |
| 4924392 | 27 HOSE AS | 1 | |
| 0054173 | 28 ELBOW | 1 | |
| 0307959 | 29 TEE-FLARED | 1 | |
| 0L1351 | 30 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1616 | 31 BOLT (1/4-20X1-IN) | 1 | |
| 1724211 | 32 SPACER (10.5X22X50.8-MM THK) | 2 | |
| 1808424 | 33 SEAL-O-RING | 2 | |
| 1984765 | 34 WASHER-HARD (8.8X20X8-MM THK) | 3 | |
| 1984766 | 35 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 1A2029 | 36 BOLT (3/8-16X1.125-IN) | 16 | |
| 1B2790 | 37 BOLT (5/16-18X1.375-IN) | 2 | |
| 2141048 | 38 SPACER (8.8X16X4-MM THK) | 2 | |
| 2B2695 | 39 BOLT (5/16-18X0.875-IN) | 1 | |
| 3537957 | 40 GROMMET | 6 | |
| 3E4352 | 41 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 3E4353 | 42 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 4B0831 | 43 BOLT (5/16-18X3.75-IN) | 2 | |
| 4B3388 | 44 BOLT (5/16-18X1.125-IN) | 3 | |
| 5M2894 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 5P0537 | 46 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5S0003 | 47 NUT (5/16-18-THD) | 8 | |
| 6V3251 | 48 SEAL-O-RING | 1 | |
| 6V4248 | 49 BOLT (M10X1.5X25-MM) | 2 | |
| 6V5064 | 50 SEAL-O-RING | 1 | |
| 6V6609 | 51 SEAL-O-RING | 2 | |
| 6V9169 | 52 NUT (13/16-16-THD) | 2 | |
| 7N1637 | 53 STUD (3/8-16X2.5-IN) | 1 | |
| 8S4951 | 54 CAP (FLARED) | 1 | |
| 8T1887 | 55 CLIP (SLOT) | 6 | |
| 8T1888 | 56 CLIP (TAB) | 6 | |
| 8T7934 | 57 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 9M1974 | 58 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 9S8750 | 59 NUT-FULL (1/4-20-THD) | 1 | |
| 9S8752 | 60 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 61 WASHER-HARD (10.2X22.5X3-MM THK) | 3 |
