System And Components
304-3285 LINES GP-EXHAUSTS/N B7C100-UP
Group No: 304-3285
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4161 | 1 CLAMP | 2 | |
| 7C2901 | 2 COVER-ELBOW | 2 | |
| 2600179 | 3 MANIFOLD | 2 | |
| 2751037 | 4 SUPPORT | 1 | |
| 2751039 | 5 SUPPORT AS | 1 | |
| 3031239 | 6 BRACKET | 4 | |
| 3159880 | 7 BRACKET | 1 | |
| 3159881 | 8 BRACKET | 1 | |
| 1984767 | 9 WASHER-HARD (13.5X30X12-MM THK) | 36 | |
| 6V3823 | 11 BOLT (M12X1.75X60-MM) | 8 | |
| 6V5686 | 12 BOLT (M16X2X50-MM) | 4 | |
| 6V7687 | 13 LOCKNUT (M12X1.75-THD) | 8 | |
| 6V7673 | 14 BOLT (M12X1.75X50-MM) | 4 | |
| 6V8149 | 15 NUT (M12X1.75-THD) | 8 | |
| 3692483 | 16 BOLT-HIGH TEMPERATURE (M12X1.75X90-MM) | 8 | |
| 6C5304 | 17 BOLT (M16X2X110-MM) | 4 | |
| 9X8268 | 18 WASHER (17.5X30X3.5-MM THK) | 8 |
