Assembly
100%

349-3980 MANIFOLD GP-EXHAUST -INLET, TURBINES/N B7C100-104

Group No: 349-3980
Part NumberPart NameQty
24649241 GASKET2
30258892 CLAMP-BAND8
34508833 BRACKET2
34508884 SPACER (11X20X15-MM THK)8
34892525 BELLOWS AS4
34935596 BOLT-HIGH TEMPERATURE (M10X105X45-MM)8
34939787 MANIFOLD GP-EXHAUST (RH)1
32178937A BOLT (M10X1.5X55-MM)4
48078487B MANIFOLD-EXHAUST1
34508817C ELBOW1
35361137D SPACER (11X20X20-MM THK)4
34939798 MANIFOLD GP-EXHAUST (LH)1
19847689 WASHER-HARD (17.5X32X8-MM THK)3
6V442910 BOLT (M16X2X40-MM)2
322583011 BOLT (M12X1.75X50-MM)2
359320112 SPACER (13.5X30X8-MM THK)2
8T029913 BOLT (M16X2X30-MM)1
