System And Components
361-7259 LINES GP-EXHAUSTS/N KEX1-131
Group No: 361-7259
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 2006345 | 2 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2681611 | 3 TEE AS | 1 | |
| 2681610 | TEE-BULKHEAD | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 3353459 | 4 HOSE-AIR | 1 | |
| 3617243 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3617244 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3623368 | 7 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3659662 | 8 HOSE | 1 | |
| 3659666 | 9 HOSE AS | 1 | |
| 3659667 | 10 HOSE AS | 1 | |
| 3659668 | 11 HOSE AS | 1 | |
| 3659669 | 12 HOSE AS | 1 | |
| 3659671 | 13 HOSE AS | 1 | |
| 3659674 | 14 TUBE | 1 | |
| 3659675 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4168310 | 16 HOSE AS | 1 | |
| 1488316 | 17 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1536233 | 18 UNION AS | 1 | |
| 6V8732 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1645580 | 19 TEE AS | 1 | |
| 6V9489 | TEE-BULKHEAD | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645624 | 20 ELBOW AS | 2 | |
| 9X2085 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1647908 | 21 ELBOW AS | 1 | |
| 8T7546 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1716467 | 22 UNION AS | 1 | |
| 8T5082 | UNION | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1S0994 | 23 CLIP (LOOP) | 2 | |
| 2H3924 | 24 LOCKWASHER | 2 | |
| 3G6883 | 25 CLIP (SLOT) | 2 | |
| 3G6884 | 26 CLIP (TAB) | 2 | |
| 4M0061 | 27 BOLT (5/16-18X0.75-IN) | 1 | |
| 5K1094 | 28 LOCKWASHER | 2 | |
| 5M3062 | 29 BOLT (3/8-16X0.75-IN) | 3 | |
| 6D1641 | 30 CLIP (LOOP) | 3 | |
| 6V9169 | 31 NUT (13/16-16-THD) | 1 | |
| 6V9170 | 32 NUT-BULKHEAD (1-14-THD) | 1 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 35 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4195 | 36 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4224 | 37 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4896 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T6703 | 39 CLAMP-HOSE | 4 |
