System And Components
380-4480 SHIELD GP-HEATS/N KEX1-105
Group No: 380-4480
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3648501 | 1 PLATE | 2 | |
| 3648511 | 2 PLATE AS | 1 | |
| 3648512 | 3 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3648513 | 4 SHIELD GP-HEAT (CEM) | 1 | |
| 3772950 | 5 PLATE AS | 2 | |
| 3874513 | 6 PLATE AS | 1 | |
| 4230407 | 7 COVER AS | 1 | |
| 5C7261 | NUT (M8X1.25-THD) | 4 | |
| 8T4200 | BOLT (M8X1.25X16-MM) | 4 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 1428194 | RIVET | 4 | |
| 2495155 | PLATE-WARNING (HOT SURFACE) | 1 | |
| 7X7729 | 8 WASHER (11X25X3-MM THK) | 22 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4195 | 10 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 11 BOLT (M10X1.5X35-MM) | 10 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 13 BOLT (M12X1.75X35-MM) | 4 | |
| 1984777 | 14 WASHER-HARD (11X25X10-MM THK) | 4 |
