System And Components
361-7252 LINES GP-EXHAUSTS/N KDH239-381
Group No: 361-7252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 4 | |
| 2696650 | 2 ADAPTER | 1 | |
| 2815968 | 3 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5465 | ELBOW | 1 | |
| 3368614 | 4 CLIP (LOOP) | 1 | |
| 3652227 | 5 HOSE AS | 1 | |
| 1444613 | 6 ANGLE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4177554 | 7 BRACKET | 1 | |
| 4177555 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4177556 | 9 HOSE AS | 1 | |
| 4177557 | 10 HOSE AS | 1 | |
| 4177558 | 11 HOSE | 1 | |
| 4177569 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4341303 | 13 SHIELD AS | 1 | |
| 1488378 | 14 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1S1015 | 15 CLIP (LOOP) | 2 | |
| 5K1094 | 16 LOCKWASHER | 2 | |
| 6V9169 | 17 NUT (13/16-16-THD) | 1 | |
| 8M2773 | 18 CLIP (LOOP) | 2 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 2 | |
| 6D4246 | 22 CLIP (LOOP) | 5 | |
| 3585522 | 23 BOLT-FLANGE HEAD (M6X1X25-MM) | 2 | |
| 4341304 | 24 INSULATION | 1 | |
| 4341305 | 25 INSULATION | 1 | |
| 3264516 | 26 TIE-CABLE | 5 | |
| 5P4961 | 27 CLAMP-HOSE | 2 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 2 | |
| 8T4133 | 29 NUT (M10X1.5-THD) | 2 | |
| 8T4195 | 30 BOLT (M10X1.5X30-MM) | 3 |
