System And Components
295-5199 DRIVE GP-FANS/N RDR1-179
Group No: 295-5199
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3158228 | 1 BRACKET AS | 1 | |
| 8H9189 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 3158235 | 2 ADAPTER-FAN | 1 | |
| 3272476 | 3 SPRING AS | 2 | |
| 3548449 | 4 PULLEY-FAN (4-GROOVE) | 1 | |
| 3548448 | 5 PULLEY (4-GROOVE) | 1 | |
| 3418061 | 6 DRIVE GP-FAN | 1 | |
| 3803118 | 7 BRACKET | 2 | |
| 3803120 | 8 BELT TIGHTENER GP | 1 | |
| 3803127 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 7E9515 | 10 V-BELT SET (INCLUDES 4-BELTS, FAN DRIVE) | 1 | |
| 1782255 | 11 PIN | 2 | |
| 1984778 | 12 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 2284710 | 13 SPACER (13.8X30X20-MM THK) | 2 | |
| 3B4617 | 14 PIN-COTTER | 2 | |
| 3D0472 | 15 STUD-TAPERLOCK (1/2-13X2.80-IN) | 4 | |
| 4L9337 | 16 BOLT (3/8-16X1.5-IN) | 6 | |
| 5M1932 | 17 STUD-TAPERLOCK (1/2-13X2.17-IN) | 6 | |
| 5P1076 | 18 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6V8188 | 19 NUT (1/2-13-THD) | 17 | |
| 7X0325 | 20 BOLT (1/2-13X2.5-IN) | 4 | |
| 7X0333 | 21 BOLT (1/2-13X4.75-IN) | 4 | |
| 7X0338 | 22 BOLT (1/2-13X6-IN) | 1 | |
| 7X3391 | 23 WASHER-HARD (13.5X32X6-MM THK) | 6 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8T4896 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9L0553 | 26 STUD-TAPERLOCK (1/2-13X4.25-IN) | 3 |
