295-5199 DRIVE GP-FANS/N RDR507-UP

Group No: 295-5199

Part Number	Part Name	Qty
3158228	1 BRACKET AS	1
8H9189	DOWEL	1
1114379	SHAFT-TIGHTENER	1
5139274	2 DRIVE GP-FAN	1
4511330	3 SPRING AS	2
3548449	4 PULLEY-FAN (4-GROOVE)	1
3548448	5 PULLEY (4-GROOVE)	1
3803118	7 BRACKET	2
3803120	8 BELT TIGHTENER GP	1
3803127	9 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
7E9515	10 V-BELT SET (INCLUDES 4-BELTS, FAN DRIVE)	1
1782255	11 PIN	2
1984778	12 WASHER-HARD (13.5X30X12-MM THK)	2
2284710	13 SPACER (13.8X30X20-MM THK)	2
3D0472	15 STUD-TAPERLOCK (1/2-13X2.80-IN)	4
4L9337	16 BOLT (3/8-16X1.5-IN)	6
5P1076	18 WASHER-HARD (13.5X30X4-MM THK)	7
6V8188	19 NUT (1/2-13-THD)	11
7X0325	20 BOLT (1/2-13X2.5-IN)	4
7X0333	21 BOLT (1/2-13X4.75-IN)	4
7X0338	22 BOLT (1/2-13X6-IN)	1
7X3391	23 WASHER-HARD (13.5X32X6-MM THK)	6
8T4223	24 WASHER-HARD (13.5X25.5X3-MM THK)	7
8T4896	25 WASHER-HARD (10.2X18.5X2.5-MM THK)	6
4481522	26 STUD-TAPERLOCK (1/2X13-THD)	3
3B4627	28 PIN-COTTER	2
5368912	29 BUSHING	4
